The Myers MS4SD/MSB4SD model pumps are suited for wet-well installation in a wide variety of municipal, industrial and building trades applications. Their solids handling ability make them a wise choice for Municipal Sewage Lift Stations, Industrial Sewage Transfer and Dewatering Storm Water. Sewage pumps are necessary to move sewage from a building to the sewer system and in many cases, from the sewer system to a treatment plant. In the case of larger commercial installations, collection systems are designed to accumulate and transfer wastewater efficiently. Examples of this are motels, apartment buildings or industrial plants that tie in with sewer mains or on-site treatment facilities.
Municipal Sewage Lift Stations, Industrial Sewage Transfer, Dewatering of Storm Water
Motor The Fully Enclosed Oil-Filled Motor Efficiently Dissipates Heat and Locks out Moisture so you Receive Reliable Pumping Service, CPE Jacketed Power Cord Sealed by Both the Cord Grip and the Epoxy Barrier, Stainless Steel Shaft Eliminates Corrosion and Fatigue to Give Longer Pump Life. The Minimum Shaft Overhang Decreases Deflection and Increases Bearing and Seal Life., Ball Bearings The Heavy Duty Ball Bearings, Upper (radial) and Lower (thrust), are Submerged in Oil to Provide Permanent Lubrication and Ensure Long Service Life., Mechanical Seal Constructed with a Ceramic Stationary Face and a Carbon Rotating Face for Long Service Life., Impeller Two-Vane, Semi-open Design for Efficient Operation without Clogging. The Impeller has Pump-Out Vanes to Prevent Material Buildup around Shaft and Seal., Vertical Discharge Model MSB4SD Handles 3 inch Spherical Solids and has a Flanged 4 inch Vertical Discharge., Sensor Probe A Seal-Failure Sensor Probe (for connection to a seal failure alarm) is Standard on Three-Phase Units and Available as an Option on Single-Phase Models.
VOLTAGE: 1ø, 230V, 60Hz, HORSEPOWER: 5.0 HP, AMP DRAW (full load): 29.5, MOTOR TYPE: Enclosed, Oil Cooled Induction, VFD Suitable, RPM: 1750, MAXIMUM HEAD: 56’, MAXIMUM CAPACITY: 720 GPM, SWITCH TYPE: Manual, DISCHARGE PIPE SIZE: 4.0" Vertical Flange, MAXIMUM SOLIDS HANDLING SIZE: 3.0", IMPELLER TYPE: Ductile Iron, Balanced, Two-Vane, Semi-Open, CORD LENGTH: 35', CORD SIZE: 10-4; Type: SOOW, W, BODY CONSTRUCTION: Class 30 Cast Iron, MAXIMUM LIQUID TEMPERATURE: 140°F (60°C), CONTROL BOX REQUIRED
MYERS LIMITED WARRANTY, Myers® warrants to the original consumer purchaser (“Purchaser” or “You”) of the products listed below, that they will be free from defects in material and workmanship for the Warranty Period shown below, ProductWarranty Periodwhichever occurs first:, Jet pumps, small centrifugal pumps, submersible pumps and related, accessories 12 months from date of original installation, or 18 months from date of manufacture, Fibrewound Tanks 5 years from date of original installation, Fibrewound Tanks 5 years from date of original installation, Sump/Sewage/Effluent Products 12 months from date of original installation, or 36 months from date of manufacture, Battery Backup Units, MBSP-2, MBSP-2C, MBSP-3, MBSP-3C 12 months from date of original installation, or 18 months from date of manufacture, 24 months from date of original installation, or 30 months from date of manufacture, Wastewater Solids Handling Pumps 12 months from date of shipment from factory or 18 months from date of manufacture, Our warranty applies only where such products are used in compliance with the requirements of the applicable product catalog and/or manuals. For additional information, please refer to the applicable standard limited warranty featured in the product manual., Our warranty will not apply to any product that, in our sole judgement, has been subject to negligence, misapplication, improper installation, or improper maintenance. Without limiting the foregoing, operating a three-phase motor with single phase power through a phase converter will void the warranty. Note also that three phase motors must be protected by three-leg, ambient compensated, extra-quick trip overload relays of the recommended size or the warranty is void., Your only remedy, and MYERS’s only duty, is that MYERS repair or replace defective products (at MYERS’s choice). You must pay all labor and shipping charges associated with this warranty and must request warranty service through the installing dealer as soon as a problem is discovered. No request for service will be accepted if received after the Warranty Period has expired. This warranty is not transferable., MYERS SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, OR CONTINGENT DAMAGES WHATSOEVER., THE FOREGOING LIMITED WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE FOREGOING LIMITED WARRANTIES SHALL NOT EXTEND BEYOND THE DURATION PROVIDED HEREIN., Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on the duration of an implied warranty, so the above limitations or exclusions may not apply to You. This warranty gives You specific legal rights and You may also have other rights which vary from state to state., This Limited Warranty is effective April 1, 2014, and replaces all undated warranties and warranties dated before April 1, 2014.
