100 XP - SlurryChamp

100 XP

Heavy Duty Hydraulic Submersible Slurry Pump

NUMBER ONE FOR RELIABILITY, STRENGTH & ENDURANCE

100mm heavy duty pump with a replaceable casing and drainless motor suitable for use as an excavator attachment. For use with an excavator rated at 10-25t.

• Single piece cast iron body to enhance rigidity and reduce wear
• Bearings run in oil bath for lubrication and cooling
• Twin volute casing design to reduce rotational imbalance and increase lifetime of bearings and seals
• Rotating inducer creates hydrodynamic shock waves to re-suspend settled particles beneath the pump inlet
• Single stage, open vane impeller
• Precision bearings
• Non pressurised mechanical seal
• Bent axis swash plate piston motor without case drain

100 quantity

Pump Data

Design fluid handled Slurry Maximum fluid SG 2.0 kg/l Maximum fluid solids content 55% by weight Maximum particle size 32 mm Weight 525 kg Maximum fluid temperature 90 °C Recommended pH range 4-10 Outlet diameter 100 mm Maximum flow 230 m3/hr @ 1500rpm Maximum head 51 m (5.0 bar) @ 1800rpm Impeller diameter 320 mm Impeller tip speed 24 m/s @ 1800rpm Peak efficiency 62 % Maximum submergence depth* 28 m Motor displacement 63cc Speed range 1200 - 1800rpm

*As standard, can be deeper if required.

Other Data

Hydraulic service live ports SAE J518 Code 62 3/4 inch (6000psi) Allowable hydraulic pressure 250 bar Hydraulic service drain port 3/4 inch – 16UNF-2B Required hydraulic oil supply RPM Water Slurry SG 2.0 Kg/l 1200rpm 73 Litres per minute @ 65 bar 73 Litres per minute @ 130 bar 1500rpm 93 Litres per minute @ 98 bar 93 Litres per minute @ 196 bar 1800rpm 108 Litres per minute @ 125 bar 108 Litres per minute @ 250 bar

Dimensions

Pump Curve
