Submersible Dredge Pump
Kingda submersible dredge pump has unparalleled sludge suction capacity and reliability, and excellent non-clogging performance can ensure long-term operation of the pump.
Get Price！
800WNQ | Submersible Dredge Pump | Underwater Operations
Kingda 800WNQ submersible dredge pump, with single shell design and bidirectional sealing function.
The pump can be installed on the submersible pipe or mechanical arm of the dredger, and can submerge in the water to suck up riverbed mud and sediment.
Its strong mud suction performance can handle solid particles up to 14 inches in diameter to ensure that no clogging occurs.
Kingda submersible dredge pump, built for harsh dredging environment.
Submersible Dredge Pump for High-Solids and Harsh Dredging
Kingda submersible dredge pump uses high-chromium alloy wear parts, which can minimize the wear of wear parts when handling large particles and high concentrations of abrasive slurries.
The submersible dredge pump equipped with an agitator can greatly reduce the accumulation of solid sediments at the bottom of ponds and rivers, easily remove the bottom mud, and pump slurries containing sand, gravel, and rocks.
The strong and sturdy mud suction capacity can even be used in tailings transportation and gravel mining. With excellent reliability and stability, it can continuously transport high-concentration solid slurries and effectively reduce the number of maintenance.
Kingda can also provide hydraulic submersible dredge pumps that can be installed on excavators or backhoe dredgers. The flexible installation feature makes it more versatile.
Contact an Expert to Select a Pump >>>
Kingda Submersible Dredge Pumps Selections
Contact an Expert to Select a Pump >>>

KZQ Series Submersible Dredge Pump
KZQ submersible dredge pump is a vertical structure, integrated with the motor and equipped with an agitator.
It can efficiently pump high-concentration solid-liquid mixtures and easily cope with harsh dredging environments. It can also be connected through a special interface and used as an excavator dredging pump.
• Equipped with suction strainer
• Integrated submersible motor
• Fully protected forced cooling
• High chrome alloy components
• Long service life

WNQ Series Submersible Dredge Pump
WNQ submersible dredge pump is specially designed for handling large solid slurry particles.
It can pass solid particles with a maximum diameter of 350mm (14 inches) to ensure that there will be no clogging. It can be immersed in water to suck silt and sediment and has an unparalleled service life.
• No clogging
• Transport large particle slurry
• Long distance transportation
• Long-term operation
• Bidirectional waterproofing
Submersible Dredge Pump Specs
KZQ Dredge Pump
Capacity(m³/h)	50 ~ 3500
Head(m)	10 ~ 120
Discharge Diameter(mm)	50 ~ 350
Material	Alloy Wear-resisant Material
KZQ Series Pump PDF	Download
WNQ Dredge Pump
Capacity(m³/h)	136.8 ~ 25000
Head(m)	10 ~ 40
Discharge Diameter(mm)	152 ~ 1000
Material	Alloy Wear-resisant Material
WNQ Series Pump PDF	Download
KZQ Series Pump Curve
Working Range of KZQ Submersible Dredge Pump
(only for preliminary selection)
Select a Pump Now

WNQ Series Pump Curve
Working Range of WNQ Submersible Dredge Pump
(only for preliminary selection)
Select a Pump Now

Submersible Dredge Pump Manufacturers Since 1948
As a submersible dredge pump manufacturer, Kingda not only provides submersible dredge pumps related to the dredging industry, but also provides customers with complete and efficient fluid delivery solutions.
Kingda has developed supporting products specifically for dredge pumps, such as dredging pump sets, electric drives, power supply systems, sewage systems, monitoring systems, and remote communication systems.
Through these advanced equipment, we enable customers to run the entire dredging project at the best efficiency, greatly reducing manpower and material resources, and minimizing operating costs.
Contact Expert Today ！

FAQ
What is hydraulic submersible dredge pump?
Hydraulic submersible dredging pumps do not require motor drive, but rely on hydraulic power. Compared with ordinary submersible dredging pumps, hydraulic submersible dredging pumps have greater torque and can efficiently perform dredging operations on the bottom of the lake.
Hydraulic submersible dredging pumps can be installed on the excavator mechanical arm and can directly go deep into the water to suck sediment and silt. No power supply equipment is required, which is easier to maintain.
What is a submersible dredge pump with cutter head used for?
The submersible dredging pump with a cutter head can efficiently remove sediment or solid waste from the river bottom.
The cutters on both sides of the submersible dredging pump can easily cut up sharp and hard gravel, and after the sediment is stirred and mixed with water, it is sucked in by the submersible dredging pump and discharged to the shore.
